Clutch Disc - SACHS Performance

Item number: 881861.999836


336,89 EUR

including 19% VAT., no shipping costs

Recommended retail price: 354,62 EUR
(You save 5 %, that is 17,73 EUR)
Available now!

Shipping time: 1 - 2 workdays

NON-EU CUSTOMERS

With your order 19% VAT will be deducted.



Description

Diameter [mm]: 200 - Number of Teeth: 24 - Hub Profile: 18,3x20,4-24N
Transmittable torque [Nm]: 250
Clutch disc, torsion damped, with special organic clutch friction material

Manufacturer compare numbers
LADA
11186-160 1130
2110-1601130
2112-1601130

OPEL
664 144
664 175
664 300
90 217 144
90 217 145
90 289 982
90 289 983
90 296 195
90 296 481

SEAT
032 141 031 K
032 141 032 A

VOLKSWAGEN
032 141 031
032 141 031 A
032 141 031 B
032 141 031 C
032 141 031 D
032 141 031 E
032 141 031 K
032 141 031 L
032 141 031 M
032 141 031 N
032 141 031 P
032 141 031 Q
032 141 032 A
036 141 032 A

Manufacturer

Manufacturer: ZF Race Engineering GmbH, Ernst-Sachs-Straße 62, 97424 Schweinfurt, Deutschland, www.zf.com

performance-clutch-vw
SACHS Performance Kupplungsscheibe 881861

Innovative Engineering.

  • Higher transmittable torque
  • Higher thermal resistance
  • Higher burst number of revolutions
  • Longer life span
  • The torque damper has a higher stop position
  • Start Performance similar to OE
  • Effortless exchange with OE clutch disc
SACHS Clutch Disc - Function and Structure

Technical Details.

Clutch discs with torsion springs function as a vibration damper between engine and gearbox.

SACHS Performance clutch discs with organic friction material have a superior thermal resistance, are more resistant against rpm's as OE discs and are able to transmit higher torque. That makes it extremely useful for all kind of street tuning and for vehicles that are often driven with their maximum gross vehicle weight.

Installed together with the SACHS Performance clutch cover, you´ll experience the perfect combination between suitability for daily use and great drive experience.

Quality - Made in Germany.

The clutch systems from ZF SACHS Race Engineering have brought motor sports teams worldwide to the forefront, from mass sports to Formula 1.

The knowledge gained from these race series has been flowing into the development of High Performance products for years.

The SACHS Performance clutches are assembled by hand. This guarantees at all times the highest quality attributes in clamping load and release characteristics.

SACHS Performance Clutch Applications

Typically applications include:

  • Chip-Tuning, turbocharger and supercharger modifications
  • Vehicles with maximum gross vehicle weight and according to high load (towing trailers, campers)
  • 1/4 mile-race
  • Race circuit (endurance race, clubsport, autocross)
  • Rally (e.g. group N)
  • Slalom, Drift Racing

SACHS Performance clutch in the VAG Motorsport

SACHS Performance Clutch for VW, Audi, Seat, Skoda

ZF SACHS has been a partner of Volkswagen Motorsport since 2003. SACHS develops dampers and clutches for the VW Polo R WRC in the World Rally Championship (WRC). Moreover, ZF SACHS equips all vehicles in the VW Scirocco R-Cup and racing cars such as the Audi TT Cup and Audi R8 LMS.

DTM

Since the 2012 season, the three premium brands Audi, BMW and Mercedes-Benz have been fully relying on clutch systems from SACHS for all their DTM vehicles.

The racing clutch Formula Carbon Clutch 4/140Y has four carbon clutch plates. The clutch transmits a torque of up to 900 Nm and is designed for long durability.

SACHS Performance Clutch Navigator

24 Hours Nürburgring

Seven of the top ten teams lately relied on ZF SACHS clutches at the greatest long-distance race in Germany - including the first four of the overall rankings at the famous Nurburgring 24 Hour.

Porsche crossed the finish line in third place, whose 911 is equipped with SACHS racing clutches and dampers. The BMW Motorsports teams who came fourth and sixth, the seventh-placed Audi and ninth-placed Nissan all use SACHS clutches in their power transmission.

Partners of ZF SACHS Race Engineering

SACHS-BMW MotorsportSACHS VW MotorsportSACHS Porsche MotorsportSACHS Toyota HybridSACHS Super GTSACHS DTMSACHS TudorSACHS Honda Racing
